3 x HDMI Fan-free Industrial Computer GT9000
3*HDMI+2LAN+GPIO+SIM Card slot+6*RS232+8USB+PS/2
Products Features
– Brushed Full Aluminum Alloy Black color shell, Exquisite production
crati on outside design.
– Fanless system without cooling fan, no any noise, work as long as 24 hours.
– Multi ports Support GPIO+Embedded with SIM Card slot support 4G Module
– 6*RS232(3 line), COM1 COM2 support set to RS485/RS422
– Dual Gigabit LAN RJ45+8USB Port+3HDMI+GPIO+PS/2.
– Support 3 HDMI display output synchronously.
– Can be mounted on the wall by long screws
-Support Restore AC Power loss/LAN PXE boot/ WOL on windows 7
Product Details
Specification
Ordering information
Product Details
Fan-free Inustrial Embedded BOX PC GT9000 with 3HDMI Display output/ Internal SIM Card slot support SIM Card for 3G/4G Module to get network for some products with hard working
environments which can’t use wifi network. it with rich I/O Ports like GPIO/RS232 RS485 Dual LAN RJ45,8USB Ports for connecting with multiple device
for Various industry uses because of the features Compact, Space-saving, Fanless design, Zero noise disturbance, Low power consumption and Energy saving
Widely Application Area: Industrial Automation / AI / IOT Internet of Things/Smart Education /Smart Medical/Smart City /Digital Signage/Cloud Computing/Smart
Robot/Smart Transportation/New Retail(Kiosk)/Network Security etc…
Specification
| Basic Information: | |||
| CPU | 1. Intel Core i5-9300H Quad-core 8threads 2.4Ghz up to 4.1Ghz 8MB Cache with Intel UHD 630 Graphics TDP 45W 2. Intel Core i7-9750H Six-core 12threads 2.6Ghz up to 4.5Ghz 12MB Cache with Intel UHD 630 Graphics TDP 45WTDP 45W 3. Intel Core i5-10200H Quad-core 8threads 2.4Ghz up to 4.1Ghz 8MB Cache with Intel UHD 630 Graphics TDP 45WTDP 45W 4. Intel Core i7-10870H Eight-core 16threads 2.2Ghz up to 5.0Ghz 16MB Cache with Intel UHD 630 Graphics TDP 45WTDP 45W | ||
| TDP | 45W | ||
| Chipset | Intel SOC | ||
| BOIS | AMI BIOS, ACPI supported | ||
| Memory | 1 x SO-DIMM DDR4 Slot Support 4GB/8GB/16GB DDR4 2133/2400/2666Mhz | ||
| OS | Windows 7/Windows 8/Windows 10/Linux | ||
| Audio | ALC662 chip Support 6 channels of sound | ||
| Network | Onboard 2* intel i211+i219 Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN | ||
| Video | Intel UHD 630 Graphics. Triple display output synchronously | ||
| 4G | Full hight 4G Module support. with SIM Card slot | ||
| Storage: | |||
| M.SATA | 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s | ||
| SATA | 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s | ||
| M.2 | 1 x M.2 2280 Nvme/SATA | ||
| Wi-Fi: | |||
| Module | 1 x mini PCIE-half port for Wi-Fi module | ||
| Antenna | 2 x inner RF cables and 2 x external antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 12V DC In | ||
| PS2 | 1 x PS2 | ||
| Gpio | 1 x GPIO | ||
| USB | 4 x USB2.0, 4 x USB3.0 | ||
| Display | 3 x HDMI 1.4 Output | ||
| COM | 6*RS232/RS422/RS485 COM Port(BIOS Settings) | ||
| LAN | 2 x RJ45 Giga LAN | ||
| Audio | 1 x MIC, 1 x SPK | ||
| Power and Working Environment: | |||
| Input | DC100-240V AC/50-60Hz | ||
| Output | 12V 10A | ||
| Operating Temperature | 0/+60 Centigrade | ||
| Storage Temperature | -20/+ 70 Centigrade | ||
| Relative Humidity | 0%~90% (non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | Calls on function automatically, Wake-On-LAN,PXE | ||
| Size | 230mmx 175mmx50mm | ||
| Weight | Net 1.5kg, Gross 2.5kg | ||
| Shell | Aluminum Alloy with Black color | ||
| Cooling Mode | Fanless | ||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | COM | Power |
| GT9000 | I5 9300H | Intel® UHD Graphics 630 | 2.40~4.10 GHz | 3 x HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 SATA/NVME SSD | 2 | 8 | 6 | 12V/10A |
| GT9000 | I7 9750H | Intel® UHD Graphics 630 | 2.6~4.50 GHz | 3 x HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 SATA/NVME SSD | 2 | 8 | 6 | 12V/10A |
| GT9000 | I5 10200H | Intel® UHD Graphics | 2.4~4.10 GHz | 3 x HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 SATA/NVME SSD | 2 | 8 | 6 | 12V/10A |
| GT9000 | I7 10870H | Intel® UHD Graphics | 2.2~5.00 GHz | 3 x HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 SATA/NVME SSD | 2 | 8 | 6 | 12V/10A |
