Mini Firewall PC 4 LAN Celeron J6412 J6413
4 x Intel i226-V+1 x COM+1 x HDMI, 1 x DP+1 x USB3.0+5 x USB2.0+1x MIC, 1 x SPK
-4xIntel i225-V/i226-V B3 2.5G RJ45 LANs, 2xUSB3.0, 2xUSB2.0, 1xRJ45 COM console.
-2xDDR4 SODIMM non-ecc ram slot, max support 32GB.
-Support two storage: 1xM.2 2280 NVMe 2280+1×2.5”SATA SSD/HDD.
-1xHD-MI2.0 and 1xDP1.4 support dual 4K@60Hz UHD video display.
-1xSIM slot, 1xMPCIE wireless slot, support WiFi/3G/4G(3 choose 1) connection.
-Support AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.
-Full Aluminum Alloy solid-built shell with three-sided ice thorns, excellent cooling performance.
-Fanless system without cooling fan, work as long as 7×24 hours.
Product Details
Specification
Ordering information
Product Details
JIRUICC Mini Firewall Computer GT4L with J6412 / J6413 / N100,supported AES-NI. with Rich ports :4 x Intel i226-V+1 x COM+1 x HDMI, 1 x DP+1 x USB3.0+5 x USB2.0+1x MIC, 1 x SPK
Support HDMI+DP Dual Display. This pfsense firewall router with 4*Intel I226 network card support 2.5GbE which can bring you faster network usage.
This firewall mini pc is fanless and slient router pc and preinstall with pfSense, also it support OPNsense/OpenWrt/Unbutun/windows and other popular open-source software solutions.
It is Widely used in: Network Security / Banking and Finance / Healthcare / Government and Public Sector / Education Institutions / E-commerce and Retail / Information Technology (IT) Services / Energy and Utilities
By using a firewall on your PC, you can significantly enhance your computer’s security and reduce the risk of unauthorized access, data breaches, and malware infections.
It is an essential component of a layered security approach, working alongside other security measures like antivirus software, regular updates, and safe browsing practices.
Specification
| Basic Information: | |||
| CPU | 1.Intel Celeron N5100 Quad cores, 4 threads up to 1.1Ghz-2.80 GHz, 4M Cache, Intel UHD Graphics | ||
| 2.Intel Cele-ron N5105 Quad cores, 4 threads 2.00 GHz-2.90GHz 4M Cache Intel UHD Graphics | |||
| 3.Intel Pentium Gold Processor 7505,Dual core 4threads up to 3.50 GHz, 4M Cache, Intel UHD Graphics | |||
| 4. Intel Core i3-1115G4 Dual cores, 4 threads 3GHz-4.1GHz 6M Cache Intel UHD Graphics | |||
| 5. Intel Core i5-1135G7 Quad cores, 8 threads 2.4GHz-4.2GHz 8M Cache Intel Iris Xe Graphics | |||
| 6. Intel Core I7-1165G7 Quad cores, 8 threads 2.8GHz-4.7GHz 8M Cache Intel Iris Xe Graphics | |||
| TDP | 10W | ||
| Motherboard Size | 120 x 120 mm customized size | ||
| BOIS | AMI BIOS, ACPI supported | ||
| Chipset | Intel Geleron | ||
| Memory | 2*SODIMM memory slot 4GB/ 8GB/ 16GB/32GB RAM DDR4 | ||
| OS | Windows 7/Windows 8/Windows 10/Linux/pfSense | ||
| Network | 4 x Intel i225-V B3(2.5G network card), 4 x Intel i226-V | ||
| Video | Intel UHD Graphics | ||
| Storage: | |||
| MSATA | 1 x M.2 Nvme 2280 128GB/256GB/512GB/1TB/2TB optional | ||
| SATA | 1* 2.5inch SATA HDD 500GB/ 1TB / 2TB Max | ||
| Wi-Fi: | |||
| Module | 1 x mini PCIE-half port for Wi-Fi module | ||
| Antenna | 2 x inner RF cables and 2 x external antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 12V DC In | ||
| LED | 1 x Power LED, 1 x HDD LED | ||
| USB | 2 x USB3.0+2 x USB2.0 | ||
| Display | 1xHD-MI2.0 and 1xDP1.4 support dual 4K@60Hz UHD video display | ||
| LAN | 4*Onboard Intel i225-V B3 2.5G RJ45 LAN | ||
| SIM | 1 x SIM Card slot | ||
| WIFI | Dual band 2.4GHz/5.0GHz(Optional need pay extra USD8/PCS) | ||
| Power and Working Environment: | |||
| Input | DC100-240V AC/50-60Hz | ||
| Output | DC12V-4A 5.5*2.5 DC12V-7A 5.5*2.5 | ||
| Operating Temperature | -20/+60Centigrade | ||
| Storage Temperature | -20/+70 Centigrade | ||
| Relative Humidity | 0%~90%@30 (non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | Support AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN | ||
| Size | 178*122*55mm | ||
| Weight | Net 1.2kg, Gross 2kg | ||
| Shell | Black color aluminum alloy | ||
| Mounting | Can be mounted back of monitor or wall by optional VESA mount | ||
| Cooling Mode | Fanless | ||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | ||
| Optional | 1xUser Manual, 1xVESA mount | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| GT4L-J6412 | N100 | Intel UHD Graphics | 3.40 GHz | 1 x DP/1 x HDMI | 1 x SO-DIMM DDR5 | 1 x M.2 NVMe SSD/1 x 2.5 inch SATA | 4 | 6 | 12V4A |
| GT4L-J6412 | J6413 | Intel UHD Graphics | 1.80~3.00 GHz | 1 x DP/1 x HDMI | 2 x SO-DIMM DDR4 | 1 x M.2 NVMe SSD/1 x 2.5 inch SATA | 4 | 6 | 12V4A |
| GT4L-J6412 | J6412 | Intel UHD Graphics | 2.0~2.60 GHz | 1 x DP/1 x HDMI | 2 x SO-DIMM DDR4 | 1 x M.2 NVMe SSD/1 x 2.5 inch SATA | 4 | 6 | 12V4A |
