Windows 11 Pro Mini PC Intel Twin Lake N150 (4C/4T, UP to 3.6GHz)
Products Features
Model name: M6s-N150
– Smart tiny case 2.83*2.83*1.75inches compact design.
– 1 x M.22242 NVME/SATA
– Onboard 12GB LPDDR5 4800Mhz
– Support Dual Display: 1*HDMI2.0 4K@60Hz, 1*USB-C 4K@60Hz
– USB3.2*3+1*HDMI2.0 +1*USB-C+Audio+1*RJ45 1000mbps
– Built-in Wi-Fi and Bluetooth with internal antennas make the signal more
stable and stronger.
– Support PXE, Auto Power On, RTC, Wake On LAN
Product Details
Specification
Ordering information
Product Details
2025 Latest INTEL TWIN LAKE N150 PROCESSOR – The M6s N100 mini pc uses the latest Twin Lake N150 CPU 4 Core 4 Threads 6MB cache, Turbo up to 3.6GHz.
The N150, as an enhancement to the Alder Lake N100, delivers an overall performance boost of approximately 6% to 10%.
Perfect for everyday tasks, office work, and use as an HTPC, offering greater convenience compared to traditional desktop PCs.
12GB DDR5 RAM & M.2 SSD STORAGE – JIERUICC M6s-N150 tiny pc is onboard 12GB DDR5 RAM, M.2 2280 NVMe/SATA SSD up to 2TB.
Our mini desktop PC starts up in moments, handles multiple browser tabs and software applications seamlessly, and transfers files swiftly.
RICH INTERFACE – JIERUICC M6s-N150 Micro PC is equipped with USB 3.2*3, up to 5Gbps/S, HDMI(4K@60Hz)×1, 3.5mm Audio Jack.
Supports WiFi 5/BT5.0, and Gigabit Ethernet RJ45 1000Mbps network connectivity
This Small PC supports multiple device connections and can be used with servers, monitoring equipment, office equipment, displays, projectors, TVs, etc.
4K DUAL SCREEN DISPLAY – The Mini Desktop Computer M6s-N150 features upgraded Intel Graphics with 24EUs and a 1GHz frequency, offering support for 4K video playback and AV1 decoding.
Pair it with a projector to create a home theater experience and enjoy diverse entertainment options.
Features – This Small pc supports Wake On LAN, PXE Boot, RTC Wake, and Auto Power On, ideal for use as a server.
Specification
| CPU | Processor Type | Intel Twin Lake N150 Max Turbo 3.6Ghz, 4Core 4Threads 6M Cache, Intel Graphics /24EUS/1Ghz |
| Process | 10nm | |
| L3 Cache | 6MB | |
| Memory | DDR | Low Power DDR5 |
| Memory | 12GB LPDDR5 4800Mhz | |
| Display | 1*HDMI2.0 4K@60Hz, 1*USB-C 4K@60Hz | |
| Bettery | Bettery | CR2032 |
| TPM | Built-in | Firmware TPM2.0 |
| I/O | ||
| LED indicator | Power | Blue |
| Button | Physical buttons | Power |
| Adapter | Power input | type-C PD 12V/3A |
| USB Port | Data transmit | USB3.2*3 |
| Type-C | TYPE C | type-C USB（USB3.0/PD)*1, 12V/3A |
| Earphone Jack | Audio output | 1*∮3.5mm |
| HDMI | HD Video output | Support 1*HDMI2.0, Support 4K 60HZ |
| M.2 Interface | Storage | Support M.2 2242 SSD Nvme/SATA |
| Wireless | Built-in | Intel WlFI 5 / BT 5.0 |
| BT | Built-in | BT5.0 |
| Ethernet port | Giga LAN(RJ45) | 1* RJ45 LAN 1000Mbps |
| Storage | 1*M.2 2242 SATA/NVMe | |
| Hot Keys | Power Button | 1 |
| Power | TYPE C | AC 100~240V, 50/60Hz,12V/3A |
| Physical Characteristics | Dimension(L x W x H) | 2.83*2.83*1.75inches |
| Weight(g) | 190g | |
| Software | Support OS | Windows10/11 pro/ubuntu/Linux |
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| M6s-N150 | N150 | Intel Graphics /24EUS/1Ghz | 4 Cores 4 Threads up to 3.6GHz | 1*HDMI2.0 4K@60Hz, 1*Type-C 4K@60Hz | Onboard 12GB LPDDR5 | 1 x M.2 2242 Nvme/SATA SSD | 1 | USB3.2*3 | 12V/3A |
